Q: What is the distance from the wall to the inside of the door?

A: The distance from the wall to the inside of the door can be calculated using the following formula: (2-1/4") - (thickness of door). For example, if your door is 1-1/2" thick then you will apply the following formula: (2-1/4") - (1-1/2") = 3/4". In this example the distance between the wall and the inside of your inner door is 3/4".

Q: What is the distance from the wall to the outside of the door?

A: The distance from the wall to the outside of the door is 2-1/4”.

Q: What size are the lag bolts and the spacers for mounting the track?

A: The lag bolt is 3 3/4 inches long. The spacer is 1 3/8 inches tall.

Q: What is the material of the roller wheel?

A: The roller wheel is made of nylon to minimize rolling noise

Q: What is the width and thickness of the track?

A: The width is 1 1/2'' and the thickness is 1/4''.

Contractor/Designer Login

Single Door Hardware

Product Features

Package includes all the hardware kit you need to install a sliding barn door: rollers and bolt kit, track, spacers, lag bolts. (door is not included)
The standard door thickness for our hardware is from 1 3/8” to 1 3/4”.
The spacing between each hole is Standard 16”. Track lengths 8 ft and under are one single track. Longer tracks will be two or more pieces.
The minimum clearance (from top of the door to the ceiling) you need to install this barn door hardware is 6”.
Recommend using a mounting board equal in thickness to opening trim and equal to hardware length
Installation kit designed for mounting into wood structure, concrete mounting bolts and anchors not included

$100.00 – $160.00

Finish

Length (Ft)

Roller Design

Additional information

Finish	Black Rustic, Brushed Nickel
Length (Ft)	4, 4.5, 5, 5.5, 6, 6.6, 7, 7.5, 8, 9, 10, 11, 12
Roller Design	Classic, Straight, T-shape, Spoke Wheel

Description

QUALITY MATERIALS – premium carbon steel to make the hardware heavy-duty and sturdy. The black powdered coating gives the hardware a matte finish. High-quality nylon wheels to reduce noise when sliding door. Each hardware kit can hold a total door(s) weight up to 220 lbs.

INSTALLATION INSTRUCTIONS – step by step instructions with USA standard fractional inch measurements, self-explanatory pictures, and concise word instructions
